BH1200-830 Roll Forming Machine
Technical Parameters
  • Frame of machine: Welded structure with beam steel tube of special shape
  • Forming of guide feeding: Side roller type
  • Forming machine type: Wallboard and chain drive
  • Diameter of shaft: ¢80mm
  • Link chain: 16A single row
  • Motor power of forming machine: Hydraulic motor
  • Line speed of forming machine: 8-12m/min
  • Steps of forming machine: 10 steps
  • Roller material: Superior forged 45# steel
  • Thickness of roller chromium coating: 0.05mm
  • Pressure: 20Mpa
  • Hydraulic station motor power: 7.5kw
  • Hydraulic station Oil pump: Gear pump
  • Cutting ways: Hydraulic
  • Cutting blade: Cr12 with heat treatment, HRC 58º-60º
  • Thickness of the coil: 0.7-1.5mm
  • Feeding width: 1200mm
  • Precision to length: ±2mm
  • Frequency converter: Panasonic (Made in Japan)
  • Computer system adopt PLC controlling: Panasonic (Made in Japan)
  • Machine size: 6500×1400×1500(mm)
  • Total Weight: 8T
